Model No.B23ColorBlack & Customizable
Electric System
Motor48V500W Rear integrated wheel motorBattery48V 10Ah lithium battery
ControllerIntelligent controllerDisplayKT LCD Display
PAS Sensor12 magnet cadence sensorThrottleThumb Throttle
Charger2A, 110-240V applied
Main Components
FrameAlu alloyForkMOZO 20inch snow fat sus fork
HandlebarPromax HB-T303,W620*22.2*2.6TStemFH-03W foldable and adjustable
BrakeF&R Tektro hydraulic disc brakeBrake LeverAlu alloy
TyreKenda 20”*4.0RimDouble Wall Rim
SpokeStainless SteelLightHead Light, Rear light
ChainwheelProwheel 52T with plastic coverCrankProwheel, Alu alloy 170mm
ChainKMC Z7, SteelGearShimano 7-spd
Shift LeverThumb TypeKickstandAlu alloy/ Steel
SaddleJustek 5693DSN foldable typeGripHL,125mm length,black
PedalBlack Comfortable PedalRackNo
Range31-60kmCharging Time3-6h
Max. Load120kgMax. Speed50km/h
Warranty1 year for the whole piece

KT LCD Display

The clear display shows all the necessary information,riding speed, single mileage and accumulated mileage…It also has cruise control function, intelligent power display function here you can also select your individiual support.

F&R integrated wheel motor

It is paired with integrated wheel motor,the tyre cushioning pressure and comparative shock resistance are excellent,less fatigue,and the handlebars can be freely extended even on steep hills.

Tektro Hydraulic Disc Brake

This model uses hydraulic disc brakes. Its handlebars are very gentle, which means that when we ride with hydraulic disc brakes we only need to use a small amount of force to get a lot of braking power.
