SPECIFICATIONS
Model No. | B20 | Color | Black & Customizable |
Electric System | |||
Motor | 48V500W Rear integrated wheel motor | Battery | 48V 10Ah lithium battery |
Controller | 48V20A Intelligent controller | Display | KT LCD Display |
PAS Sensor | 12 magnet cadence sensor | Throttle | Thumb Throttle |
Charger | 2A, 110-240V applied | ||
Main Components | |||
Frame | Alu alloy 6061 | Fork | MOZO suspension fork |
Handlebar | PROMAX HB-T303,W620*22.2*2.6T | Stem | FH-03W foldable and adjustable |
Brake | F&R Tektro M300 mechanical disc brake with 160mm rotor | Brake Lever | Alu alloy |
Tyre | Kenda 20”*4.0 | Rim | alloy wheel integrated with the motor |
Spoke | Alu alloy | Light | Head Light 36V DC, Rear light AAA battery |
Chainwheel | Prowheel 52T with plastic cover | Crank | Prowheel 170mm crank, Alu alloy |
Chain | KMC, Z7, Steel | Gear | Shimano 7-spd |
Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
Saddle | Justek, foldable type | Grip | Rubber |
Pedal | Comfortable pedal | Rack | Optional, Alu alloy |
Performance | |||
Range | 31-60km | Charging Time | 3-6h |
Max. Load | 120kg | Max. Speed | 50km/h |
Warranty | 1 year for the whole piece |
![](https://www.freepathebikes.com/wp-content/uploads/2022/10/细节3.jpg)
Display and Handlebar
The clear display shows all the necessary information; here you can also select your individiual support.The brake levers and the comfortable handlebar width are sporty and still comfortable to ride!
![](https://www.freepathebikes.com/wp-content/uploads/2022/10/细节2.jpg)
Integrated wheel motor
It is paired with integrated wheel motor,the tyre cushioning pressure and comparative shock resistance are excellent,less fatigue,and the handlebars can be freely extended even on steep hills.
![](https://www.freepathebikes.com/wp-content/uploads/2022/10/细节1.jpg)
Shimano 7 Speed Derailleur
The Shimano Tourney 7 speed trigger shifters offer reliable gear changes, allowing you to keep your rides efficient and smooth.
