SPECIFICATIONS
| Model No. | E18-A | Color | Black matt & Customizable |
| Electric System | |||
| Motor | Bafang, G510 M620 48V 1000W mid drive motor | Charger | 110-240v AC 50-60HZ, 48V3A Applied |
| Battery | LG 48V 15Ah Lithium battery | PAS | Torque sensor&speed sensor |
| Controller | 48V 30A Integrated controller | Throttle | Thumb throttle |
| Display | APT 860C IPS Color display | ||
| Main Components | |||
| Frame | Carbon fiber | Saddle | SR LOOKIN BASIC type |
| Front Fork | DNM USD-8FAT alu alloy with Hydraulic lockout | Pedal | Wellgo, aluminum |
| Rims | Double wall, aluminum alloy, 36H*13G | Stem | Promax, Aluminum alloy |
| Tires | CST 26”*4.8 fat tire | Brake Levers | Magura Hydraulic alloy black levers |
| Brake | F/R Magura MT4E hydraulic disc brake with 203 mm rotor (four-piston) | Crankset | Aluminum, 44T |
| Speed Shifter Lever | Sram NX 11 speed | Chain | KMC, X11 rust proof chain |
| Rear Derailleur | Sram NX 11 speed | Spoke | Stainless steel |
| Seat post | EXA, dropper seatpost | ||
| Performance | |||
| Max Speed | 42-48 km/h | Charging Time & Life | 4-5 Hours, >900 Cycles |
| Range per charge | 40-65km by PAS | Warranty | 1 year for electronic parts, 2 year for the frame |
| Loading Capacity | 120kg |
1000W mid drive motor
The full suspension carbon fiber mountain bike is driven by Bafang G510 M620 48V 1000W mid drive motor. This motor’s peak torque is 200N.m, which ensures that the cyclist can ride easily even on rough mountain roads or trails. The professional DNM rear shock absorber can make the rider feel very comfortable even on bumpy roads.
Sram 11 spd derailleur
Sram 11 NX speed provides the riders with more options whether riding on flat roads or climbing hills. The 11 speed chain is rust-resistant and requires less maintenance cost than normal chains.
Air suspension fork
The DNM air suspension fork was designed for specialized mountain bikes. It has 130mm travel and lockout. The Tektro hydraulic brake and 180mm brake rotor makes the brakes more sensitive.
