SPECIFICATIONS
| Model No. | M11 | Color | Black, White & Customizable |
| Electric System | |||
| Motor | BaFang Ultra 500w Mid Drive Motor | Battery | 48V 15Ah lithium battery(LG Cells) |
| Controller | Intelligent controller | Display | 860C IPS colorful display |
| PAS Sensor | Bafang torque sensor & 12 magnet cadence sensor | Throttle | Thumb Throttle |
| Charger | 3A, 110-240V applied | ||
| Main Components | |||
| Frame | Alu alloy 6061，smooth welding | Fork | RST Alpha 110-9 suspension fork with lock |
| Handlebar | PROMAX | Stem | PROMAX |
| Brake | Tektro HD-E350 hydraulic disc brake | Brake Lever | Alu alloy |
| Tyre | KENDA ; 27.5‘*2.1 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Head Light，Rear light |
| Chainwheel | BaFang, Steel | Crank | BaFang, Alu alloy |
| Chain | KMC, Steel | Gear | Shimano Alivio 9-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | VELO | Grip | VELO |
| Pedal | WELLGO | Rack | alu alloy |
| Performance | |||
| Range | 31-60km | Charging Time | 3-6h |
| Max. Load | 120kg | Max. Speed | 50km/h |
| Warranty | 1 year for the whole piece |
500W mid drive motor
The full suspension mountain bike is driven by Bafang M600 48V 500W mid drivemotor.It can provide sufficient power performance, and the maximum torque can reach more than 120 N.m, but the noise generated is very low. The modular design of the controller and motor makes the disassembly and assembly more convenient and improves the service response speed.
Shimano Alivio 9-spd Derailleur
Shimano Alivio 9 speed provides more gear choices for the rider. When facing different road conditions, the rider can adjust the gear to ride calmly.
RST Alpha suspension fork with lock
When encountering bumpy road surface, the shock absorber can reduce the vibration and the huge impact brought by the road surface, so that the rider can get a better riding experience.
