SPECIFICATIONS
| Model No. | M15 | Color | Black and Customizable |
| Electric System | |||
| Motor | TrunkRun M06 36V 250W mid motor | Battery | 36V10AH lithium battery(Chinese cells) |
| Controller | Intelligent controller | Display | LCD display |
| PAS Sensor | TrunkRun speed sensor | Throttle | thumb throttle |
| Charger | 36V2A, 110-240 Applied | ||
| Main Components | |||
| Frame | Alu alloy 6061 | Fork | Suntour XCM suspension fork with lock |
| Handlebar | Promax HB-3018 | Stem | Promax MA-400 |
| Brake | Tektro M300 mechanical disc brake | Brake Lever | Alu alloy |
| Tyre | Scwalbe Smart sam 27.5”*2.25 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Head Light and rear light |
| Chainwheel | Trunkrun 38T | Crank | Trunkrun 170mm crank |
| Chain | KMC Z8 | Gear | Shimano Acera 8-spd |
| Shift Lever | Thumb type | Kickstand | Aluminum |
| Saddle | Velo VL-3362A mountain type | Grip | HL-G311-1A,black 130mm length |
| Pedal | YH-37X,silver | Rack | NO |
| Performance | |||
| Range | 30-50km | Charging Time | 3-5h |
| Max. Load | 120kg | Max. Speed | 35km/h |
| Warranty | 1 year for the whole piece |
Suntour XCM Suspension
When encountering bumpy road surface, the shock absorber can reduce the vibration and the huge impact brought by the road surface, so that the rider can get a better riding experience.
Shimano Acera 8-spd
The Shimano Acera 8-spd provides more gear choices for the rider. When facing different road conditions, the rider can adjust the gear to ride calmly.
Mechanical Disc Brake
The high performance of the disc brake greatly improves the safety of braking in case of riding on mountain.Disc brake in a variety of complex conditions (rain, snow, mud road) still has a relatively good performance.
Trunkrun Display
This one can display riding speed, single mileage and accumulated mileage, riding time, power gear, motor operating power and temperature, battery voltage and power status, and brake status.It also has cruise control function, intelligent power display function.
