SPECIFICATIONS
| Model No. | B19 | Color | Blue and Customizable |
| Electric System | |||
| Motor | Bafang BBS-02 48V750W mid motor | Battery | 48V12.8AH lithium battery(LG cells) |
| Controller | Bafang 48V30A | Display | 850C coloful display |
| PAS Sensor | 12 magnet cadence sensor | Throttle | thumb throttle |
| Charger | 48V2A, 110-240 Applied | ||
| Main Components | |||
| Frame | Alu alloy 6061 | Fork | RST Alpha suspension fork |
| Handlebar | Promax HB-3188 | Stem | Promax MA-400 |
| Brake | Tektro hydraulic disc brake | Brake Lever | Alu alloy |
| Tyre | MAXXIS 27.5*3.0” | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | No |
| Chainwheel | Bafang 46T with plastic cover | Crank | BaFang,170mm |
| Chain | KMC X9 | Gear | Shimano Alivio 9-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | Velo VL3362 mountain type | Grip | HL,black 130mm length |
| Pedal | Wellgo,black with reflectors | Rack | No |
| Performance | |||
| Range | 30-40km | Charging Time | 3-6h |
| Max. Load | 150kg | Max. Speed | 45km/h |
| Warranty | 1 year for the whole piece |
Tektro Hydraulic Disc Brake
We have fitted it with oil-pressure brakes, which allow active braking on both sides, and the rapid response of the brakes provides better security for our riding safety.
Display and Handlebar
The clear desplay shows all the necessary information; here you can also select your individiual support.The brake levers and the comfortable handlebar width are sporty and still comfortable to ride!
Shimano Alivio 9-spd
The Shimano Alivio 9 speed trigger shifters offer reliable gear changes, it provides smooth shifting during our rides, allowing us to adjust the speed gears for uphill and downhill and our rides will be easier.
Bafang BBS02 48V 750W mid motor
Can provide plenty of power for your ride. As a brushless motor it has a fast response time, high starting torque and low maintenance costs.This powerful motor provides you with great power on uphill for an excellent riding experience.
