SPECIFICATIONS
| Model No. | F12 | Color | White & Customizable |
| Electric System | |||
| Motor | LAX 36v250W rear wheel hub motor | Battery | 36V9AH lithium battery（seat post,Chinese cells) |
| Controller | Intelligent controller | Display | JANA black LCD Display |
| PAS Sensor | 12 magnet cadence sensor | Throttle | No |
| Charger | 2A, 110-240V applied | ||
| Main Components | |||
| Frame | Alu alloy | Fork | Steel Regid Fork |
| Handlebar | Promax HB-T303 22.2*25.4*600 | Stem | FH一05W 25.4*68*240mm ext. |
| Brake | F&R Tektro mechanical disc brake | Brake Lever | Alu alloy |
| Tyre | Kenda K924 20”*2.1 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Front light |
| Chainwheel | Prowheel 48T with plastic cover | Crank | Prowheel, 170mm |
| Chain | KMC Z7 | Gear | Shimano 7-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | Justek 5693DSN foldable type | Grip | HL,black with 125mm length |
| Pedal | YH,black with reflectors | Rack | Rear Rack |
| Performance | |||
| Range | 31-60km | Charging Time | 3-5h |
| Max. Load | 100kg | Max. Speed | 25km/h |
| Warranty | 1 year for the whole piece |
LCD Display and Folding Handlebar
The clear desplay shows all the necessary information; here you can also select your individiual support.The brake levers and the comfortable folding handlebar width are sporty and still comfortable to ride!
F&R Tektro Disc Brake
Tektro MD-M280 mechanical disc brake,with cable actuated mechanical disc brake,actuated with liner pull brake levers.Excellent braking for you at all times
Shimano TZ 7-spd
The Shimano TZ 7 speed trigger shifters offers reliable gear changes, provides more gear choices for the rider. When facing different road conditions, the rider can adjust the gear to ride calmly.
