Model No.F4ColorRed and Black & Customizable
Electric System
MotorLAX 36v250W rear wheel hub motorBattery36V7.5AH lithium battery(Chinese cells)
ControllerIntelligent controllerDisplayKT LCD Display
PAS Sensor12 magnet cadence sensorThrottleNo
Charger2A, 110-240V applied
Main Components
FrameAlu alloyForkSteel Regid Fork
HandlebarFK-301,22.2*25.4*W:600mm*6°StemFoldable and Adjustable
BrakeF&R Tektro V- brakeBrake LeverAlu alloy
TyreKenda K935 20”*1.75RimDouble Wall Rim
SpokeStainless SteelLightFront and Rear light
ChainwheelTopwheel 52T with plastic coverCrankTopwheel, 170mm
ChainKMC Z7GearShimano TZ 6-spd
Shift LeverThumb TypeKickstandAlu alloy/ Steel
SaddleJustek 5693DSN foldable typeGripHL,black with 125mm length
PedalKW-P223,black with reflectorsRackNo
Range31-60kmCharging Time3-5h
Max. Load100kgMax. Speed25km/h
Warranty1 year for the whole piece

LCD Display

The clear display shows all the necessary information; here you can also select your individiual support.The brake levers and the comfortable folding handlebar width are sporty and still comfortable to ride!

Shimano TZ 6-spd

The Shimano TZ 6 speed trigger shifters offers reliable gear changes, provides more gear choices for the rider. When facing different road conditions, the rider can adjust the gear to ride calmly.

Folding Frame

This F4 model can be fully folded and can easily fit in the boot of the car after folding, is really very convenient.
