SPECIFICATIONS
| Model No. | C9M | Color | Lake Green & Customizable |
| Electric System | |||
| Motor | Trunkrun 48V500W mid motor | Battery | 48V15AH frame battery (LG cells) |
| Controller | Intelligent controller | Display | LCD Display |
| PAS Sensor | 12 magnet cadence sensor | Throttle | Thumb Throttle |
| Charger | 2A, 110-240V applied | ||
| Main Components | |||
| Frame | Alu alloy | Fork | Suntour NEX fork，full alloy without lock |
| Handlebar | Promax HB-T320 city type | Stem | Promax MQ-525 goose stem |
| Brake | Starunion 156P hydraulic disc brake | Brake Lever | Alu alloy |
| Tyre | Kenda 27.5”*2.1 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Front light |
| Chainwheel | Trunkrun 38T | Crank | Trunkrun, 170mm |
| Chain | KMC Z8 | Gear | Shimano Altus 8-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | SR 5564DEN city type | Grip | HL,black with 130mm length |
| Pedal | YH-37X,silver with reflectors | Rack | Rear Rack |
| Performance | |||
| Range | 31-60km | Charging Time | 3-5h |
| Max. Load | 150kg | Max. Speed | 25km/h |
| Warranty | 1 year for the whole piece |
Trunkrun 48V500W mid motor
This electric bike is equipped with Trunkrun 48V500W mid motor,with 500w of strong power, making this city bike easy to ride on the hills as well.
Shimano Altus 8-spd
The Shimano Altus 8 speed trigger shifters offers reliable gear changes, provides more gear choices for the rider. When facing different road conditions, the rider can adjust the gear to ride calmly.
Alu Alloy Rear Rack
The city bike with rear rack can help you carry some items while you are out riding,that can free up your space.A very simple and practical rack.
