SPECIFICATIONS
| Model No. | S3 | Color | Black & Customizable |
| Electric System | |||
| Motor | 48V500W direct drive motor | Battery | 48V10AH lithium battery(Chinese cells) |
| Controller | Intelligent controller,48V20A | Display | LED display |
| PAS Sensor | 12 magnet cadence sensor | Throttle | thumb throttle |
| Charger | 48V2A, 110-240 Applied | ||
| Main Components | |||
| Frame | Alu alloy 6061 | Fork | steel regid fork |
| Handlebar | PROMAX | Stem | Goose stem |
| Brake | F:Mektro M280 mechanical disc brake with 160mm rotor R: V-brake | Brake Lever | Alu alloy |
| Tyre | Kenda K1047 26”*2.125 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Head Light&rear light |
| Chainwheel | Prowheel 46T with plastic cover | Crank | Prowheel, Alu alloy |
| Chain | KMC, Steel | Gear | Shimano TZ 7-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | Baisike | Grip | STAR UNION |
| Pedal | YONGHUA | Rack | Rear Rack, Alu alloy |
| Performance | |||
| Range | 31-60km | Charging Time | 3-5h |
| Max. Load | 100kg | Max. Speed | 25km/h |
| Warranty | 1 year for the whole piece |
Prowheel Chainwheel
To achieve a better transmission, we have fitted the S3 with Prowheel chainwheel and crank to give you a comfortable drive when pedalling.
Shimano TZ Gears
Shimano TZ 7-spd allows for fast and smooth shifting, making it possible to adjust the gears for shifting smoothly at any time during your ride. Offering a comfortable ride for you.
Rear Carrier Battery
The battery is a 10AH rear carrier battery.It gives you up to 31-60 kilometers of range on a single charge, depending on the profile of your journey and how you ride. You can fully recharge the battery from empty in 5 hours through a standard household power outlet.
