Model No.F2ColorWhite & Customizable
Electric System
MotorLAX 36v250W rear wheel hub motorBattery36V10AH lithium battery(Chinese cells)
ControllerIntelligent controllerDisplayKT LCD Display
PAS Sensor12 magnet cadence sensorThrottleNo
Charger2A, 110-240V applied
Main Components
FrameAlu alloyForkZOOM suspension fork
HandlebarFK-391,22.2*31.8*W:600mm*6°riseStemfoldable and adjustable
BrakeF&R Tektro V- brakeBrake LeverAlu alloy
TyreKenda K935 20”*1.95RimDouble Wall Rim
SpokeStainless SteelLightFront and Rear light
ChainwheelTopwheel 46T with plastic coverCrankTopwheel, 170mm
ChainKMC Z7GearShimano TZ 6-spd
Shift LeverThumb TypeKickstandAlu alloy/ Steel
SaddleJustek 5693DSN foldable typeGripHL,black with 125mm length
PedalKW-P223,black with reflectorsRackRear Rack
Range31-60kmCharging Time3-5h
Max. Load100kgMax. Speed25km/h
Warranty1 year for the whole piece

MOZO Sus Fork

We have fitted F2 model with a MOZO suspension fork. This reduces the vibrations from the road, creating a more comfortable ride. The headlight provides illumination to facilitate our night riding.

F&R Tektro V-Brake

This folding ebike is equipped with Tektro V-brake, it is simple, easy to maintain and light weight.

Shimano TZ 6-spd

The Shimano TZ 6 speed trigger shifters offers reliable gear changes, provides more gear choices for the rider. When facing different road conditions, the rider can adjust the gear to ride calmly.
